HPLC Syringe Filters

Material: Nylon; Hydrophilic PVDF; Hydrophilic PTFE; Hydrophobic PTFE; PES; MCE; Hydrophilic PP; Cellulose Acetate(CA)
Qty/Pack: 100pcs/pack
Application: Filter
Payment: T/T
MOQ: 1 pack

Product Introduction

Details

1. Membrane: Nylon; Hydrophilic PVDF; Hydrophilic PTFE; Hydrophobic PTFE; PES; MCE; Hydrophilic PP; Cellulose Acetate(CA)

2. Pore Size: 0.22um and 0.45um Diameter: 13mm and 25mm

3. Usages: Whether your research requires pre-filtration

Description

Filter Membrane

Nylon /PTFE /PES/MCE/ PVDF/ CA

Pore Size, μm

0.22μm, 0.45μm

Diameter

13mm

25mm

Housing

PP

PP

Filtration Area

1.0cm2

4.3cm2

Maximum Operating Pressure

6.2bar

6.2bar

Process Volume

10ml

100ml

Hold-up Volume

< 25μl

<100μl

Inlet

Female Luer Lock

Female Luer Lock

Outlet

Male Luer Unlock

Male Luer Unlock

Flow Direction

Flow should enter from the inlet

Maximum Operating Temperature

267.8F

Sterilization

Autoclave at 249.8F at 1 bar for 20 minutes/EO/Gamma

Syringe Filters

Features

Material Characteristic


PTFE

PTFE membrane, hydrophobic, resistant to strong acid, strong alkali and high temperature, suitable for the filtration of strong corrosive solution, organic solution and gas.


PVDF

PVDF membrane, hydrophobic, low protein binding, suitable for general biological filtration, not suitable for filtration of highly corrosive liquids.


Nylon

Nylon membrane, hydrophilic, high protein binding, suitable for protein-free aqueous and organic solutions, resistant to alcohol and DMSO.


PES

Polyethersulfone resin membrane, hydrophilic, low protein binding, high flow rate, high porosity, not resistant to organic solvents and strong acid-base solutions, suitable for filtering cell culture media.


CA

Cellulose acetate membrane, hydrophilic, low protein binding, suitable for the filtration of proteins and aqueous solutions in biological samples, such as serum culture medium filtration.

Syringe Filters Package

Technical Parameter

1. Aijiren New Syringe Filter

 1.PVDF Syringe Filter
Part No. FF1322 FF1345 FF2522 FF2545
Description Pore Size: 0.22um
Diameter:13mm
PVDF Syringe Filter
Polypropylene Housing
Pore Size: 0.45um
Diameter:13mm
PVDF Syringe Filter
Polypropylene Housing
Pore Size: 0.22um
Diameter:25mm
PVDF Syringe Filter
Polypropylene Housing
Pore Size: 0.45um
Diameter:25mm
PVDF Syringe Filter
Polypropylene Housing
2. PTFE Syringe Filter
 Part No. FE1322 FE1345 FE2522 FF2545
 Description Pore Size: 0.22um
Diameter:13mm
PTFE Syringe Filter
Polypropylene Housing
Pore Size: 0.45um
Diameter:13mm
PTFE Syringe Filter
Polypropylene Housing
Pore Size: 0.22um
Diameter:25mm
PTFE Syringe Filter
Polypropylene Housing
Pore Size: 0.45um
Diameter:25mm
PTFE Syringe Filter
Polypropylene Housing
 3.PES Syringe Filter
Part No. FS1322
FS1345
FS2522  FM2545
Description Pore Size: 0.22um
Diameter:13mm
PES Syringe Filter
Polypropylene Housing
Pore Size: 0.45um
Diameter:13mm
PES Syringe Filter
Polypropylene Housing
Pore Size: 0.22um
Diameter:25mm
PES Syringe Filter
Polypropylene Housing
Pore Size: 0.45um
Diameter:25mm
PES Syringe Filter
Polypropylene Housing
 4.CA Syringe Filter
Part No. FC1322  FC1345 FC2522 FC2545
Description Pore Size: 0.22um
Diameter:13mm
CA Syringe Filter
Polypropylene Housing
Pore Size: 0.45um
Diameter:13mm
CA Syringe Filter
Polypropylene Housing
Pore Size: 0.22um
Diameter:25mm
CA Syringe Filter
Polypropylene Housing
Pore Size: 0.45um
Diameter:25mm
CA Syringe Filter
Polypropylene Housing
5.Nylon Syringe Filter
Part No. FN1322 FN1345 FN2522 FN2545
Description Pore Size: 0.22um
Diameter:13mm
Nylon Syringe Filter
Polypropylene Housing
Pore Size: 0.45um
Diameter:13mm
Nylon Syringe Filter
Polypropylene Housing
Pore Size: 0.22um
Diameter:25mm
Nylon Syringe Filter
Polypropylene Housing
Pore Size: 0.45um
Diameter:25mm
Nylon Syringe Filter
Polypropylene Housing
6.PP Syringe Filter
 Part No. FP1322 FP1345 FP2522 FP2545
 Description Pore Size: 0.22um
Diameter:13mm
PP Syringe Filter
Polypropylene Housing
Pore Size: 0.45um
Diameter:13mm
PP Syringe Filter
Polypropylene Housing
Pore Size: 0.22um
Diameter:25mm
PP Syringe Filter
Polypropylene Housing
Pore Size: 0.45um
Diameter:25mm
PP Syringe Filter
Polypropylene Housing
7. MCE Syringe Filter
Part No. FM1322  FM1345 FM2522  FM2545
Description Pore Size: 0.22um
Diameter:13mm
MCE Syringe Filter
Polypropylene Housing
Pore Size: 0.22um
Diameter:13mm
MCE Syringe Filter
Polypropylene Housing
Pore Size: 0.22um
Diameter:25mm
MCE Syringe Filter
Polypropylene Housing
Pore Size: 0.45um
Diameter:25mm
MCE Syringe Filter
Polypropylene Housing
